vp_BC55PA_SER
-
SKU:
BC55-16PA,115
-
Date Code:
2327+
-
Short Description:
60 V, 1 A NPN medium power transistors
-
Description:
NPN medium power transistor in an ultra thin SOT1061 leadless small Surface-Mounted Device (SMD) plastic package.
Table 1. Product overview Type number
Package
NPN complement
Nexperia
JEITA BC55PA
SOT1061 -
BC52PA
BC55-10PA
BC52-10PA
BC55-16PA
BC52-16PA
- Datasheet:
Stock: 0
Features
High current
Three current gain selections
High power dissipation capability
Exposed heatsink for excellent thermal and electrical conductivity
Leadless very small SMD plastic package with medium power capability
AEC-Q101 qualified
Applications
Linear voltage regulators
Power management
Low-side switches
MOSFET drivers
Battery-driven devices
Amplifiers
